DIN-KA52F
24V/1.04A, 25 W Power Supply with Din-Rail Mounting (RoHS)
ICPDAS
24V/1.04A, 25 W Power Supply with Din-Rail Mounting (RoHS).
Construction |
Power Supply Type |
AC-DC |
Construction |
Plastic Case |
Input Specifications |
AC Voltage |
Range |
100...250 V |
Frequency |
47...62 Hz |
Output Specifications |
Output Power |
25 W |
Conversion Type |
AC-DC Switching |
Output Voltage |
+24 V |
Output 1 |
Voltage |
+24 V |
Max Load |
1 A |
Parallel Operation |
No |
Cooling |
Cooling |
Convection |
Connectors |
Input Connector |
3-pin |
Output Connector |
Terminal Block |
Operation |
Operation |
Temperature |
0...70 °C |
Storage |
Storage |
Temperature |
-40...+85 °C |
Dimensions and Weight |
Dimensions |
Width |
68 mm |
Height |
50 mm |
Depth |
107 mm |
Certifications |
Certificates |
Safety |
UL 1950,CSA 22.2 No.234,TUV EN 60950 |
EMI |
FCC docket 20780 curve B,EN55022 class B |
EMS |
EN 50082-2,IEC 801-2 8kV,IEC 801-3 3V/M,IEC 801-4 2kV,IEC 801-5 2kV |
|
